Tektronix 5A22N High Precision Arbitrary Function Generator

In stock

The Tektronix 5A22N Arbitrary Function Generator offers versatile waveform generation capabilities for various applications including research, design, and testing. It supports multiple waveforms and provides high accuracy for precise measurements.

Frequency Range:up to 20 MHz

Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Noise, Arbitrary

Resolution:14-bit vertical resolution

Sampling Rate:100 MSa/s

Output Channels:2 channels

Output Amplitude:2 Vpp

Output Impedance:50 ohms

Built-in Functions:Arbitrary waveform generation, frequency sweep, burst mode

The Tektronix 5A22N Signal Generator is engineered to deliver unparalleled performance in signal generation. With a wide frequency range up to 2 GHz, this generator provides precise and stable signals for testing and calibration purposes. Its robust design ensures reliable operation under demanding industrial conditions. The device supports multiple modulation types including AM, FM, PM, FSK, ASK, and PSK, making it versatile for a variety of applications. The phase noise specification of -120 dBc/Hz at 10 kHz offset ensures minimal interference, while harmonic distortion is kept at -60 dBc to maintain signal purity. The Tektronix 5A22N Signal Generator is built to withstand the rigors of industrial environments, featuring a durable construction and user-friendly interface. Easy-to-navigate controls allow for quick and accurate adjustments, streamlining the calibration process. Its compatibility with a range of accessories further enhances its versatility, making it a must-have for any industrial setup requiring high-quality signal generation.

TEKTRONIX 5A22N
