Operating Pressure:1 to 7 kg/cm²
Actuation Speed:0.1 to 10 mm/s
Max. Load Capacity:20 kgf
Precision Control:±0.1% of full scale
Operating Temperature Range:-20°C to +80°C
Material:Aluminum alloy with stainless steel components
Electrical Input:DC 24 V
Output Stroke:101 mm
Power Consumption:≤ 2 W
Repeatability:≤ ±0.01% of full scale
Cycle Life:≥ 1,000,000 cycles
The SMC FCW504-02-X101-C is a high-performance pneumatically controlled module tailored for complex industrial automation scenarios. Its compact design and robust construction make it ideal for integrating into existing pneumatic systems with minimal space constraints.
Featuring an operating pressure range of 3 to 10 bar, this module ensures optimal performance across a wide spectrum of pneumatic applications. Its response time of ≤0.05 seconds guarantees swift activation, enhancing overall system responsiveness.
With a temperature tolerance from -20°C to +70°C, the FCW504-02-X101-C is engineered to withstand extreme conditions, ensuring reliability in harsh environments. Its ISO 1219 compliant connection type facilitates easy installation and compatibility with industry-standard components.
Suitable for small to medium-sized pneumatic systems, this module offers versatile control options including 4-20 mA current loops, pulse width modulation (PWM), and contact control, allowing for precise and flexible operation based on specific application requirements.
Equipped with an efficient power supply that consumes ≤50mA, this module optimizes energy usage without compromising on performance. It’s an indispensable component for enhancing productivity, reducing downtime, and achieving higher levels of automation in manufacturing and industrial processes.
