Manufacturer:Rockwell Automation
Model Number:845T-DZ13EDN-9
Frame Size:20
Encoder Type:Incremental
Resolution:500 pulses per revolution
Supply Voltage:10-30 VDC
Output Type:Push-Pull
Shaft Diameter:8 mm
Shaft Material:Stainless Steel
Weight:0.45 kg
Shaft Sealing:IP65
Operating Temperature:-20°C to +85°C
Storage Temperature:-30°C to +90°C
This Size 20 Frame Incremental Encoder from Rockwell Automation is built with a robust optical system that ensures reliable and precise measurements under harsh industrial conditions. The encoder’s stainless steel shaft guarantees durability and long-lasting performance, making it suitable for use in environments with high vibration and temperature fluctuations.
The encoder delivers high resolution of 10000 counts per minute, which allows for precise position control in a wide range of industrial automation applications. It supports push-pull output signals, providing stable and accurate feedback on machine movement.
Designed with environmental protection rating IP65, this encoder can withstand dust and water ingress, ensuring reliable operation even in challenging outdoor and indoor settings. Its compact frame size of 20 makes it easy to integrate into existing machinery without requiring extensive reconfiguration.
The encoder comes with a 6mm diameter stainless steel shaft that measures 10mm in length, providing a strong and durable connection point for mechanical components. With a weight of just 0.3kg, this encoder is lightweight and does not add significant burden to the overall machinery.
Installation of the 845T-DZ13EDN-9 is straightforward, thanks to its simple wiring and cable connections. Users can easily connect it to their control systems and start benefiting from its precise position control capabilities right away.
