NI NI-9505 Industrial Data Acquisition Module

In stock

The National Instruments NI-9505 is a robust 9-slot CompactDAQ chassis with built-in Ethernet connectivity, ideal for industrial automation and data acquisition applications. It provides a versatile platform for engineers and technicians looking to integrate advanced measurement capabilities.

Manufacturer:National Instruments

Model Number:NI-9505

Module Type:Analog Input Module

Input Channels:8 Channels

Resolution:16-bit

Sampling Rate:Up to 1 MHz per channel

Voltage Range:+/-10V

Accuracy:+/-0.05% FS

Isolation:Channel-to-earth isolation

Operating Temperature:-40°C to +85°C

Power Supply:5V DC

The NI NI-9505 Data Acquisition Module is meticulously designed for integration into industrial automation systems. It provides robust performance and reliability, ensuring seamless operation even in harsh environments.

This module supports up to 32 channels, offering flexibility for various industrial applications. Its high sampling rate of 1 MS/s ensures fast and accurate data collection, critical for real-time monitoring and control.

With a 16-bit resolution, the NI NI-9505 delivers precise measurements, making it suitable for demanding applications such as test and measurement, manufacturing processes, and environmental monitoring.

Designed for durability, the module operates within a wide temperature range from -40°C to +85°C, ensuring reliable performance in extreme conditions. Its compact dimensions (165mm x 100mm x 25mm) make it easy to integrate into existing systems.

The NI NI-9505 is powered by a 5V DC supply, simplifying installation and maintenance. Its lightweight design (0.3kg) makes it convenient for mounting and handling in various settings.
