National Instruments PCI-6509 Digital I/O Device

Model:PCI-6509

Interface:PCIe

I/O Channels:48

Bit Resolution:8

Max Output Frequency:1 MHz

Supply Voltage:3.3V

Temperature Range:-40°C to +85°C

Dimensions:L x W x H

:105mm x 54mm x 25mm

Weight:Approx. 145g

    Integrating advanced technology, the National Instruments PCI-6509 Digital I/O Device is an indispensable component for industrial automation systems, providing reliable and efficient signal processing capabilities.

    Featuring a robust design, this device ensures compatibility with both Windows and Linux operating systems, catering to a wide range of industrial environments and applications.

    With its 32 channels, the PCI-6509 offers a flexible configuration of 16 input and 16 output channels, enabling users to customize their setup according to specific needs.

    Equipped with a high sampling rate of up to 1 MHz, it ensures fast and accurate data acquisition, crucial for real-time monitoring and control in demanding applications.

    Designed with safety in mind, each channel supports a current limit of 50 mA, safeguarding against potential overloads and ensuring system stability.

    Compliant with TTL signal levels, the PCI-6509 ensures seamless integration with other electronic components, simplifying the setup process and enhancing compatibility across various industrial control systems.
