Heidenhain ERN1120 1024 01L-FW Encoder Module

Measurement Principle:Inductive Coupling

Resolution:1024 Counts per Revolution

Signal Type:Incremental

Output Signal:RS-422

Voltage Supply Range:4.75 VDC to 30 VDC

Operating Temperature Range:-20°C to +85°C

Protection Rating:IP67

Shaft Diameter:8 mm

Shaft Material:Steel

Weight:Approximately 120 g

    This HEIDENHAIN ERN1120 1024 01L-FW encoder is a high-quality component designed for industrial applications requiring precise position measurement. With its robust design and high-resolution output, it is ideal for integration into complex automation systems. The encoder features an incremental quadrature signal output, ensuring accurate position feedback over multiple revolutions. Its compact size and easy installation make it suitable for a wide range of machinery and equipment. The shaft, made from durable steel, ensures long-lasting performance under demanding conditions. Operating within a temperature range of -20°C to +85°C, this encoder is built to withstand harsh environments. Moreover, the IP54 protection rating guarantees dust and water resistance, making it reliable in various settings. The HEIDENHAIN ERN1120 1024 01L-FW encoder is a testament to HEIDENHAIN’s commitment to quality and precision, providing users with dependable performance in critical industrial operations.
