Model Number:SR745-W2-P5-G5-HIE
Voltage Rating:60KV
Windings Per Phase:2
Resistant Temperature Device (RTD) Type:3-wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40 character Enhanced LCD
Dimensions:Height: 9 inches, Width: 7 inches, Depth: 7 ⅛ inches
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
The GE SR745-W2-P5-G5-HIE 60KV is an advanced transformer protection system that combines cutting-edge technology with reliable performance. Designed for transformers, autotransformers, and reactors, this system provides comprehensive protection against overcurrent, overvoltage, and thermal overloads.
Key Features:
– **Enhanced 40 Character Display**: Offers an expanded keypad for easier manual entry of setpoints, enhancing operational convenience.
– **Real-Time Status Alerts**: Equipped with multiple LEDs on the front panel to provide real-time alerts about system statuses and errors, ensuring quick response and maintenance.
– **Compact and Rugged Design**: The system is designed to fit on a standard 19” panel, making it easy to install and integrate into existing setups. Its robust design ensures durability even under challenging industrial conditions.
– **Optimized Monitoring Capabilities**: With its advanced RTD type and analog output configurations, the system offers precise monitoring and control, extending the lifespan of the protected equipment.
– **Flexible Control Power Options**: Supports a wide range of control power options, including both DC and AC inputs, providing flexibility for diverse installation scenarios.
Installation is straightforward, with clear instructions included. The GE SR745-W2-P5-G5-HIE 60KV is a critical component in any transformer protection setup, offering peace of mind and reliability.
