Manufacturing Company:General Electric
Model Number:DS3800HPTK
Application Category:Mark IV DS3800
Functionality:Gate driver for the Mark IV Speedtronic series, providing precise control over turbine operations
Component Count:Fifteen long grey resistors rated at 18 Ohms ±5%, ten color-coded resistors indicating their capacity, thirteen diodes of various colors, three capacitors of varying sizes, a large glass fuse, and a small red LED
Physical Design:Comprises a thin metal divider with eight contact points, labeled from A through H and then J with triangular symbols between each letter, and equipped with two screw points and two plastic clips for easy installation
Manufacturing Information:Labeled with circuit board number, manufacturer’s logo (GE), and manufacturing location
Integrating cutting-edge technology, the GE DS3800HPTK GATE DRIVER CARD ensures reliable and efficient control in industrial applications, particularly in the power generation sector.
This card is equipped with high-quality components including long grey resistors, color-coded resistors for precision current management, and robust diodes that contribute to its superior performance.
With a wide operating temperature range and high power rating, the DS3800HPTK is designed to withstand harsh environments and deliver consistent performance over extended periods.
Installation is straightforward with a single edge labeled for easy identification and two screw points, ensuring quick setup without compromising safety.
Manufactured with meticulous attention to detail, each part is clearly marked with a letter-number system for easy reference. This card is a testament to GE’s commitment to providing premium, durable solutions for industrial control systems.
