Number of Selectable Inputs:8
Number of Selectable Outputs:4
Relay Output:Available
Serial Communication Ports:1 supporting RS232 and RS485
Encoder Support:Embedded for multi-turn absolute encoders
External Logic Power:Option for maintaining actuator position during power loss
Compliance Status:Not compliant with EU RoHS directive
Drive Size:(198.12 x 144.27 x 72.64 mm)
Input Voltage Range:100-240VAC rms, 1-Phase
Frequency Range:47-63 Hz
Output Voltage Range:100-240VAC
Continuous Output Power:1kW
Continuous Output Current:5A
Intermittent Output Current:15A
Operating Temperature:-10°C to +50°C
Storage Temperature:-20°C to +60°C
The Allen-Bradley 2098-DSD-010X Digital Servo Drive offers advanced control capabilities for complex industrial automation tasks. With eight selectable general purpose inputs and four selectable general purpose outputs, this drive ensures seamless integration with various control systems. The integrated serial communication port supports both RS232 and RS485 standards, enabling flexible data exchange with other devices.
Featuring a compact design and robust construction, the 2098-DSD-010X is engineered to withstand harsh industrial environments. Its embedded support for multi-turn absolute encoders ensures accurate position feedback even during power loss, maintaining critical operation integrity.
Designed for high performance and reliability, this drive delivers exceptional precision and speed in indexing applications. It supports pre-configured moves that can be set up for either relative or absolute positioning, catering to diverse motion control requirements.
Equipped with an option for external logic power supply, the Allen-Bradley 2098-DSD-010X ensures consistent performance by maintaining actuator positions during power interruptions. This feature is particularly advantageous in applications requiring uninterrupted operation.
While not compliant with the European Union’s RoHS directive, the drive is meticulously engineered to meet global industrial standards, offering a reliable choice for manufacturers seeking advanced servo drive solutions without the need for costly compliance modifications.
