AB 1756-IM160A Isolated Input Module – Advanced Industrial Control Solution

Model Type:Isolated Input Module

Manufacturer:Allen-Bradley

Model Number:1756-IM160A

Input Channels:16

Isolation Voltage:2500V

Operating Voltage Range:DC 12 to 60V

Operating Current Range:0 to 20mA

Operating Temperature:-40°C to +85°C

Relay Outputs:4

Communication Interface:ControlNet

Power Consumption:≤ 3.5W

Environmental Compliance:CE, UL, CSA, ATEX

    The AB 1756-IM160A Isolated Input Module boasts a compact yet robust design, optimized for space-saving installations in industrial automation environments. Its isolated input architecture ensures that each channel operates independently, significantly reducing the risk of common mode voltage issues, which enhances overall system stability.

    Featuring a wide operating temperature range, this module is suitable for use in extreme conditions, making it ideal for applications in harsh industrial settings. It supports a variety of communication protocols, including ControlNet, allowing seamless integration with other Allen-Bradley ControlLogix components.

    With its high current limit per channel, the 1756-IM160A can accommodate a broad range of sensor types, offering flexibility in industrial automation setups. The module’s efficient power consumption ensures minimal energy usage, contributing to lower operational costs.

    The 1756-IM160A complies with international safety standards, including CE, UL, and CSA, ensuring that it meets stringent industry requirements for quality and safety. Its rugged construction and reliable performance make it a trusted choice for demanding industrial applications.

    Designed for ease of use and maintenance, the AB 1756-IM160A offers quick installation and simple configuration options, minimizing downtime and streamlining system setup processes. It is an essential component for enhancing the efficiency and reliability of Allen-Bradley ControlLogix-based automation systems.
