Brand:Allen-Bradley
Model:2098-DSD-HV100X
Series:Ultra 3000
Output Current (Intermittent):46 Amps (0-peak)
Output Current (Continuous):23 Amps (0-peak)
Input Voltage:230-480V rms, 3-Phase
Auxiliary Power Supply:Yes
Nominal Input Current (AC):7 Amps
Root Means Square Input Frequency (AC):47-63 Hz
Bus Overvoltage:810V dc
Shunt On:800V dc
Dimensions:9.54 x 14.2 x 5.46 in (242.2 x 360.7 x 138.7 mm)
The 2098-DSD-HV100X is part of the Ultra 3000i Digital Servo Indexing series, known for its robust performance and reliability in various industrial applications. With a continuous output current of 23 Amps and an intermittent output current of 46 Amps, this drive delivers exceptional power efficiency.
This drive is equipped with a ControlLogix platform, ensuring seamless integration with existing systems. Its compatibility with a SERCOS interface enables sophisticated communication protocols, making it a versatile choice for complex automation tasks.
The 2098-DSD-HV100X boasts an advanced indexing feature, which facilitates precise motion control and indexing operations. Its design includes an AC line filter for optimal performance and longevity.
Key safety features include protection against bus overvoltages up to 810V DC, ensuring the drive operates safely under extreme conditions. The compact dimensions make it easy to integrate into existing machinery without compromising space.
Designed for durability, the 2098-DSD-HV100X is built to withstand harsh industrial environments, providing reliable performance even under heavy loads and repetitive cycles.
