Model Type:SLC500
Model Number:1746SC-IN04I
Manufacturer:Allen Bradley
Number Of Channels:4 (Input)
Common Mode Voltage Range:-20 To 20 V
Absolute Input Voltage:+/- 7.5 VDC Or 7.5 VAC RMS (Maximum)
Input Range:-20 To 20 MA
Absolute Input Current:-30 To 30 MA (Maximum)
Voltage Rating:Overvoltage Protection: 7.5 VAC RMS
Current Rating:Backplane Current Draw: 35 MA At 5 V, 85 MA At 24 V
Isolation:Backplane: 500 VDC, Enclosure: Open Type
The Allen-Bradley 1746SC-IN04I Analog Input Module is a high-resolution analog signal processor designed for industrial automation environments. Its primary function is to convert real-world analog signals into digital data for easy integration into control systems. With its ability to handle up to four channels of input simultaneously, this module is versatile enough to meet a wide range of industrial needs.
Designed with precision in mind, the module features overvoltage protection up to 7.5 VAC RMS, ensuring stable operation even in unpredictable conditions. The backplane current draw specification highlights its efficiency in power consumption, drawing just 35 mA at 5 V and 85 mA at 24 V. This makes it a cost-effective solution without compromising performance.
Engineered with 500 VDC isolation, this module ensures reliable signal transmission by preventing electrical interference between circuits. Its open-type enclosure allows for flexible installation and maintenance, making it suitable for various industrial settings.
This analog input module is a critical component for systems that require accurate and reliable analog data acquisition. Whether you’re monitoring environmental conditions, controlling machinery, or integrating with other automation systems, the Allen-Bradley 1746SC-IN04I provides the robust performance needed to support your operations.
